filter felt fabric for industrial filter bag dust collector
Nonwoven dust filter fabric 500gsm polyimide air filter material
Quick Detail:
dust filter cloth
1. Non-toxic and odorless
2. Long service life
3. Good stiffness, easy to pleat
4. High air permeability
5. High dust holding
Description:
Excellent resistant to hydrolysis, acids and alkalies.
good air permeability
Lower fiber release, Lower density,High mechanical characteristics
Technical Specification:
Nonwovern dust filter bag | Continuous Temperature | Peak Temperature | Description | Resistance to Acids | Resistance to Alkalis | Resistance to Oxidation | PH Value |
| Polypropylene | 90ºC | 100ºC | PP | excellent | excellent | restricted | 1-14 |
| Acrylic | 125ºC | 140ºC | AC | good | good | good | 3-11 |
| Polyester | 130ºC | 150ºC | PE | restricted | moderate | good | 4-12 |
| Polyphenylen sulfide | 190ºC | 200ºC | PPS | excellent | excellent | moderate | 1-14 |
| Nomex | 204ºC | 250ºC | Nomex | good | excellent | good | 3-14 |
| Polysulfonamide | 250ºC | 300ºC | PSA | excellent | excellent | excellent | 3-14 |
| Polymide | 260ºC | 300ºC | P84 | good | moderate | good | 3-13 |
| Polytertrafluoroethylene | 250ºC | 280ºC | PTFE | excellent | excellent | excellent | 1-14 |
| Yadi | 150ºC | 160ºC | Yadi | excellent | excellent | excellent | 3-13 |
| Glassfiber | 260ºC | 300ºC | BQ | good | good | good | 3-11 |
Specification
| Compositions | P84/P84 scrim | P84 / glass scrim |
| Weight (g/m2) | 450 | 500 | 550 | 800 | 850 | 900 |
| Thickness (mm) | 2.0 | 2.2 | 2.4 | 2.5 | 2.8 | 3.0 |
| Air permeability (m2m2/min) | 19 | 15 | 12 | 16 | 13 | 10 |
| Tensile strength (N/5×20cm) | Warp | 650 | 700 | 800 | 1800 | 1800 | 1800 |
| Weft | 1150 | 1200 | 1300 | 1800 | 1800 | 1800 |
| Tensile Elongation (%) | Warp | <35 | <35 | <35 | <10 | <10 | <10 |
| Weft | <55 | <55 | <55 | <10 | <10 | <10 |
| Working Temperature(°C) | Continues | ≤260 | ≤260 |
| Instant | 300 | 300 |
| Anti-acid | Excellent | Excellent |
| Anti-alkali | Medial | Medial |
| Anti-abrasion | Excellent | Excellent |
| The stability of water solution | Medial | Medial |
| Finishing treatment | Singeing,High temperature hot pressing | Singeing,High temperature hot pressing |
Feature:
P84 Felt filter Media provide a unique and cost effective solution
for many tough industrialbaghouse applications. Versatile and
efficient,P84 usage ranges from minerals processing, low acid coal
fired boilers, asphalt / hot mix plants, to soil remediation
facilities.P84 fibers are needled into filtration quality felts to
be sewn into filter bags suitable for use in pulse jet style
baghouses. The unique tri-lobal fiber structure of P84 provides
customers with high efficiency filtration, low pressure drop, and
reduced cleaning energy.
Notices:
1. Materials avaliable: polyester, polypropylene,Nomex , PPS, PTFE,
P84, Acrylic , glassfiber .
2. construction: welded or sewn
3. collar type: steel ring or plastic ring
4. finishing treatment: singed, calendared, heat set
5. Size available: standard and custom size.
Applications:
1. Air filters capture pollen, allergens, mold spores, and other
microscopic particles to reduce symptoms and help everyone breathe
easier.
2. medical filters made from nonwovens are key in any operating
room to keep out pathogens, bacteria or microbes that might
otherwise contaminate a sterile environment.
3. Oil filters are an important component in your car. The nonwoven
fabrics in the filter help remove contaminants from the engine oil,
hydraulic oil, trasmission oil and lubricating oil.
4. Automotive engine air intake filter helps automobile engines run
at the highest efficiency,optimum airflow helps ensure engines run
most effectively, which reduces fuel waste.
5. Filters for industrial filtration are used for dust produced in
processing industries such as grinding, separation, brushing,
transportation, drying, incinerating, etc.
FAQ
1. May I get samples?
Yes,
For OEM sample, usually takes about 5~15 days, it depends on design
and technique.
2. Can you make my logo on package?
Of course! You only need provide us your original logo file or
clear picture, so we can make it.
3. What is the payment method?
Bank transfer (T/T), Western Union, Money gram, L/C, paypal
4. How long production takes?
It is usually in 5~7 days after getting your payment and all the
details confirmed.
